Usage/Application: Grouting Brand: Vision Enterprises Pump Type: Piston Pump Power Source: Electric Model Name/Number ; IG 01 Discharge Pressure: Approx. 500 Bar Material: Mild Steel Head: 2 L Motor Horsepower: 600 Watt Maximum Discharge Flow: 1 L/min Best Value for money Epoxy Grouting Pump. Lowest price and committed for best pricing for spares. Epoxy grouting pumps are specialized tools used to inject epoxy resin into cracks and voids in concrete and other materials. They play a crucial role in construction, repair, and restoration projects by strengthening structures, preventing water infiltration, and improving overall stability. Here's a breakdown of epoxy grouting pumps: Types of Epoxy Grouting Pumps: Piston pumps: These pumps are known for their high pressure output, making them ideal for deep crack injection and heavy-duty applications. Gear pumps: Offering smooth and continuous flow, gear pumps are suitable for injecting low- viscosity epoxies and filling shallow cracks. Screw pumps: These pumps excel at handling thick and abrasive grouts, making them effective for filling large voids and gaps. Key Features of Epoxy Grouting Pumps: Flow rate: Measured in liters per minute (LPM) or gallons per minute (GPM), it determines the speed at which the epoxy is injected. Pressure output: Measured in MPa or PSI, it indicates the pump's capability to push the epoxy against resistance. Viscosity range: Different pumps can handle various viscosities of epoxy resins, from thin and fluid to thick and paste-like. Portability: Some pumps are portable and lightweight, while others are stationary and require more setup. Material compatibility: Choose a pump with components resistant to the specific epoxy resin you'll be using.

Injection Grouting Type: PU Property Type: Commercial Applicable Area: Concrete Surfaces Weight: 9 Kg Maximum Output Pressure: 450 Bar Brand: Vision Enterprises Power: 700 W Voltage: 440 V vision enterprises epocy injection grouting machine with bosch drill & steel cup PU injection grouting pumps are specialized tools used to inject polyurethane (PU) resin into cracks, voids, and other gaps in concrete and masonry structures. The resin expands and hardens, filling the gaps and strengthening the structure. Here's an overview of PU injection grouting pumps: Types: Manual pumps: These are portable and hand-operated, ideal for small-scale projects or tight spaces Electric pumps: More powerful than manual pumps, suitable for larger projects and higher injection pressures. Pneumatic pumps: Offer high flow rates and pressure for large-scale grouting jobs Key features: Mixing ratio control: Ensures accurate mixing of the PU resin and hardener in the desired ratio (typically 1:1). Injection pressure: Varies depending on the pump type and model, typically ranging from 100 bar to 750 bar. Flow rate: Determines the speed of grout injection, ranging from 0.5 L/min to 10 L/min. Material compatibility: Should be compatible with the specific PU resin and hardener being used.

Usage/Application: Grouting Pump Type: Piston Discharge Pressure: 5000 psi Brand: Vision Enterprises Maximum Discharge Flow: 1.1 L/min Voltage: 240 V Frequency: 50 Hz Power Source: Electric Model Number: VEIG01 Power: 500 Watts Availalbe Pressure: Can generate upto 13500 psi.

Usage/Application: Grouting Pump Type: Radial Piston Pumps Material: MS and Plastic Brand: Vision Enterprises Voltage: 220 V Frequency: 50 Hz Power Source: Electric Pressure of Restarting: Less than 150 Ba Weight: 9 Kg Maximum Output Pressure: 500 Bar Safe range of High-Pressure Hose: Less than 300 Bar Flow Rate: 1.0 l/min Power: 690 W Model Name/Number: VE IG-02 Safe range of Switch Valve: Less than 350 Bar Material of Application: Double liquid-type PU Foam Waterproofing plugging agent, insulation material Double liquid-type quick-setting PU/EPOXY reinforcing agent 1:1 Matching double-liquid non particle low-viscosity liquid. Application Field: Subway Station, Tunnel, Culvert, Foundation Improvement, Soil Settlement, Reservoir, Port Project, Top Slab, Crack, Construction Join, Shrinkage Crack, Basement hairline crack etc. water stop projects Full set of Machine Include: Drill: 1 set 550W High pressure hose: 2 pc 5M Shut-off value: 1 set Repairing kit: 1 set Seal set: 1 set T type wrench: 2 set Rubber pad: 1 pcs Zerk: 1 pc Filter: 2 pcs Material cup: 2 set

Usage/Application: Grouting Pump Type: Centrifugal Pump Material: Mild Steel Surface Finish: Polished Number of Holes: 4 Holes Piston Grout Pumps: Powerful Precision for Filling the Gaps Piston grout pumps are robust workhorses in the construction and geotechnical world, designed to inject grout, a thick, high-pressure slurry, into cracks, voids, and crevices to stabilize and strengthen structures. They're the go-to choice for applications demanding high pressure, controlled flow, and reliable performance. Here's what makes them tick: Operation: A piston driven by hydraulic or electric power reciprocates within a cylinder, creating a suction and discharge action. Grout is drawn from a hopper or tank, then pumped through hoses and packers to the targeted location. Pressure relief valves prevent overpressurization and equipment damage. Key Features: High pressure capabilities: Piston pumps can generate pressures exceeding 5,000 psi, crucial for pushing grout into deep cracks or against significant backpressure. Positive displacement: Unlike gear or centrifugal pumps, piston pumps deliver a consistent volume of grout per stroke, regardless of resistance, ensuring precise application. Durable construction: Robust components like steel bodies and heavy-duty pistons withstand harsh jobsite conditions and abrasive grout mixtures. Versatility: Various piston pump models cater to different needs, with varying sizes, pressure outputs, and power sources (electric, hydraulic, gasoline, or diesel). Applications: Concrete crack and void filling: Repairing structural elements like foundations, beams, and walls for increased stability and longevity. Soil stabilization: Injecting grout to strengthen loose ground or anchor structures like retaining walls. Geotechnical applications: Securing rock bolts, filling voids around tunnels and shafts, and stabilizing slopes. Waterproofing: Sealing leaks in dams, basements, and other structures.

Brand: Vision Enterprises Material: Stainless Steel Packaging Type: Box Surface Finished: Polished Product Code: 249125 Material Grade: SS316 Piston assembly: This is the core component of an airless pump, responsible for generating the pressure needed to push paint or other materials through the sprayer. Piston rod: This connects the piston to the pump handle or motor, converting its up-and-down motion into pressure. Packing kit: This includes various seals and gaskets that keep the piston assembly working smoothly and prevent leaks.

Max Flow Rate: 15L/MIN Usage/Application: Industrial Phase: Pneumatic Pump Type: Diaphragm Material: Teflon Motor Horsepower: 1:1 Color: Blue Voltage: 220V Frequency: 50Hz Diaphragm movement is minimal, therefore lowering the pulsation of material supply and reducing wear on pump components. Easy Handling and Installation: Weighing only 4.5 KG., the unit is easily picked up with one hand. Connect air spray gun and hose can be easily connected. Additional Information: Production Capacity: 15L/MIN Packaging Details: BOX TYPE Diaphragm pumps are positive displacement pumps that use a flexible diaphragm to move fluid. The diaphragm acts like a piston, alternately expanding and contracting to create suction and pressure. This design offers several advantages, including: Self-priming: Can easily draw liquid from a tank or container without needing to be pre-filled. Can handle viscous fluids and solids: Suitable for abrasive or chunky materials compared to other pump types. Leak-free operation: No risk of contamination as the fluid doesn't come into contact with the pump mechanism. Low maintenance: Simple design with few moving parts makes them reliable and easy to maintain. Applications: Diaphragm pumps are used in a wide range of industries and applications, including: Chemical processing: Transferring corrosive or hazardous fluids. Food and beverage: Pumping viscous liquids like syrups and dough. Medical: Circulating fluids in medical equipment. Construction: Degrouting and pumping slurries. Agriculture: Spraying pesticides and fertilizers. Aquaculture: Aerating ponds and tanks.

Material Aluminum and PVC Usage/Application: Grout Pump Brand: Vision Enterprises Packaging Type: Packet Shape: Ring Shaped Country of Origin: Made in India There are many different types of injection grout pump spares available, depending on the specific pump you have and the type of grouting you're doing. Here's a breakdown to help you identify what you might need: By Pump Type: Epoxy/PU Grouting Pumps: These pumps typically require spares like packing sets, piston rings, check valves, and nozzles specific to the material being pumped. Cement Grouting Pumps: Spares for these pumps often include wear plates, impellers, seals, and gaskets that can handle the abrasive nature of cement grout. Electric vs. Pneumatic Pumps: Depending on your pump type, you might need different spare parts like motors, solenoids, air regulators, or pressure gauges. Common Spares: Packings and Seals: These create a tight seal between moving parts and prevent leaks. Choose the right material based on the grout type and pressure requirements. Valves and Check Valves: These control the flow of grout and prevent backflow. Different types include one-way valves, foot valves, and needle valves. Pistons and Rods: These are the core components that push the grout. Ensure they're the correct size and material for your pump and application. Hoses and Fittings: These connect the pump to the injection point and need to be able to handle the pressure and material. Choose the right length and diameter based on your needs. Nozzles and Packers: These control the direction and flow of grout at the injection point. Different types are available for specific applications.

Model Name/Number: HB Warranty: 1 Year Motor Warranty Usage/Application: Water Base Paint, Oil Paint, Emulsion, Etc Max Flow: 2.7Lpm Heating Mode: Piston Type Motor Type: DC Motor We "Vision Enterprises" are the leading manufacturer and importer of a wide range of Electric Airless Paint Sprayer, Airless Painting Machine, Wall Putty Spray Painting Machine, Grouting Pump, etc. Additional Information: Production Capacity: 2.7Lpm Packaging Details: Machine Comes With 15mtr Hose, Airless Gun and Extension Rod with Box Packing
